OVERVIEW

BENEFITS

FEATURES AT A GLANCE

PERFORMANCE AND PRODUCTIVITY

The updated Cat® C32 engine and powerful torque converter with ECPC (Electronic Clutch Pressure Control) Transmission provides superior performance. The ECPC Transmission with controlled throttle shifting regulates engine speed, torque converter lock-up and transmission clutch engagement for smoother shifts, reduced clutch wear and longer component life.

Rear wheel spindles are solid steel for longer life, and the rear suspension cylinders have been inverted to minimize contamination. These rugged cylinders use large diameter bore and low pressure nitrogen/oil design for long life with minimal maintenance. TRANSMISSION
Electronically senses engine conditions and automatically up-shifts one gear to prevent over speeding. If over speeding occurs in the top gear, the lock-up clutch is disengaged, and the brakes are applied.

DO MORE WITH LESS FUEL

The 777E fuel saving strategies find opportunities to reduce fuel burn and fuel costs. 1) Economy Mode modifies engine maps to take advantage of steady grades and level ground, reducing power and fuel burn. 2) Speed Limiting automatically selects the most fuel efficient gear and speed for the terrain instantaneously. 3) Engine Idle Shutdown identifies when the truck is in park and idles for more than a preset time, and initiates engine shutdown to conserve fuel.

DESIGNED FOR OPERATORS

The 777E cab interior, is completely redesigned to provide better visibility and comfort for the operator. Features include a new dash, advisor display and redesigned center console. Rollover and Falling Object Protection is an extension of the truck frame.

OPERATOR WORK STATION
The all new operator station interior is ergonomically designed for total machine control in a comfortable, productive and safe environment. All controls, levers, switches and gauges are positioned to maximize productivity and minimize operator fatigue. Designed for excellent all-around visibility and clear sight lines to the haul road, the large viewing area offers exceptional visibility. The well positioned hand rails ensure three point contact for safe and easy access and emergency egress for the operator.

COMFORT SEAT
The Cat Comfort Seat uses full air suspension to smooth rough rides, and has a retractable four-point seat belt with a shoulder harness. A Trainer seat with a lap belt to facilitate on-the-job training.

MAXIMIZE PERFORMANCE

TRANSMISSION
Electronically senses engine conditions and automatically up-shifts one gear to prevent over speeding. If over speeding occurs in the top gear, the lock-up clutch is disengaged, and the brakes are applied..

TOP-TIER SERVICE AND SUPPORT

Cat ET service tool provides service technicians with easy access to stored diagnostic data through the Cat Data Link.

Critical power train data, including transmission shifting, engine speed and fuel consumption, provides service technicians with enhanced diagnostic capability to reduce downtime and operating costs

AUTOMATIC CONROLS

TRACTION CONTROL
The Traction Control System electronically monitors and controls rear wheel slippage for greater traction and enhanced truck performance in poor underfoot conditions. If slippage exceeds a set limit, the rear wet brakes engage to slow the spinning wheel. Torque is then automatically transferred to the wheel with better traction and optimum control.

AUTOMATIC RETARDER CONTROL (ARC)(optional)
ARC controls braking on grade electronically, maintaining consistent engine speed, lower fuel burn, and better control.

SECONDARY STEERING
Automatically engages if power source for the normal steering fails.

LONG TERM VALUE AND DURABILITY

Cat trucks are known throughout the industry for reliable, long-life frames. Built for off-road maneuvering and haul road conditions, Caterpillar uses castings in high stress areas and box section construction to manage torsion-loading. The frames are welded on a platform that rotates 360 degrees, allowing consistent, deeply-penetrating welds. Each frame is subject to quality and conformance testing prior to assembly.

SUSPENSION AND STEERING
Cat integrated steering and suspension system is designed for precise steering, excellent maneuverability, minimal tire wear and superior ride control.

BRAKES
The Cat Front dry caliper with rear oil-cooled multiple disc brakes deliver reliable performance and control in the most extreme haul-road conditions. Wet brakes on rear wheels and gear limiting during body up operations are both standard. If equipped with front oil cooled multiple disc brakes, four corner retarding with a 40/60 percent front/rear split provides superior control in slippery conditions and minimizes wheel lock-up.

DURABILITY
Rear wheel spindles are solid steel for longer life, and the rear suspension cylinders have been inverted to minimize contamination. These rugged cylinders use large diameter bore and low pressure nitrogen/oil design for long life with minimal maintenance.
