US
METRIC
910K
KEY SPECS
- Net Power 72kW
- Rated Net Power - SAE J1349 72kW
- Rated Net Power - Rated Engine Speed 2200r/min
OVERVIEW
FEATURES AT A GLANCE
High Performance
With its high full turn tipping loads and breakout forces, the K Series delivers a powerful solution for all customer applications.
Ease of Operation
State of the art electro-hydraulic system provides low effort, fine control with fast cycle times. All-in-one joystick helps keep eyes on the work. Operator can adjust machine responsiveness with the push of a button, which allows the operator to set up the machine exactly the way they want it based on the application.
Parallel Lift Loader Linkage
The Cat® Optimized Z-bar Loader linkage combines the digging efficiency of a traditional Z-bar with tool carrier capabilities for great performance and versatility. With parallel lift and high tilt forces throughout the working range you can safely and confidently handle loads with precise control.
SPECIFICATIONS
- Net Power 72kW
- Rated Net Power - SAE J1349 72kW
- Rated Net Power - Rated Engine Speed 2200r/min
- Maximum Gross Power - Maximum Engine Speed 2350r/min
- Maximum Gross Power - ISO 14396 74kW
- Maximum Gross Power - ISO 14396 (DIN) 74kW
- Maximum Gross Power - SAE J1995 76kW
- Engine Model Cat C4.4
- Operating Weight 7492kg
- Cooling System 21.5l
- Fuel Tank 154l
- Hydraulic System - Including Tank 98l
- Engine Crankcase 8.8l
- Rated Bucket Capacity 1.9m³
- Maximum Gross Power 100kW
- Bucket Capacities 1.3-1.9 m3 (1.7-2.5 yd3)
- ROPS ISO 3471:2008
- FOPS ISO 3449:2005 Level II
- Maximum Flow - Implement Pump - 3rd Function, Maximum Flow 90l/min
- Front Fixed; Locking differential (standard)
- Note (1) Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.
- Transmission 3.4l
- Relief Pressure - Tilt Cylinder - 4th Function Maximum Working Pressure 21000kPa
- Stroke 127mm
- Hydraulic Tank 55l
- Rated Net Power - ISO 9249 72kW
- Forward and Reverse - Low Range, Speed Range 1* 10km/h
- Maximum Flow - Steering Pump 66l/min
- Hydraulic Cycle Time - Total Cycle Time 12.5s
- Forward and Reverse - Low Range, Speed Range 2* 20km/h
- Maximum Flow - Implement Pump 122l/min
- Hydraulic Cycle Time - Raise, Ground Level to Maximum Lift 5.2s
- Note (2) The declared dynamic operator sound pressure levels per ISO 6396:2008*, when properly installed and maintained, is 77 dB(A).
- Maximum Flow - Implement Pump - 4th Function, Maximum Flow 90l/min
- Steering Cycle Times - Full Left to Full Right - At 2,350 rpm: 90 rpm Steering Wheel Speed 3.2s
- Relief Pressure - Tilt Cylinder 34000kPa
- Steering Articulation Angle - Each Direction 40°
- Note (1) Other tire choices are available. Contact your Cat dealer for details.
- Rated Net Power - ISO 9249 (DIN) 72kW
- Displacement 4.4l
- Maximum Working Pressure - Steering Pump 18500kPa
- Note *Creeper Control allows speed control from a stand still up to 10 km/h (6.3 mph). The Creeper Control will only work in Range 1.
- Maximum Gross Torque - SAE J1995 455N·m
- Note (4) *The measurements were conducted with the cab doors and windows closed.
- Hydraulic Cycle Time - Float Down, Maximum Lift to Ground Level 3.7s
- Emissions Engine meets U.S. EPA Tier 3/EU Stage IIIA emission standards.
- Hydraulic Cycle Time - Rackback 2.2s
- Standard Size 15.5-25 12PR
- Bore 105mm
- Number of Steering Wheel Turns - Full Left to Full Right or Full Right to Full Left 3.75turns
- Rear Oscillating �11 degrees; Locking differential (Standard)
- Hydraulic Cycle Time - Dump, at Maximum Reach 1.4s
- Axles - Front Center Differential 7.5l
- Relief Pressure - Tilt Cylinder - 3rd Function Maximum Working Pressure 21000kPa
- Axles - Rear Center Differential 7.5l
- Maximum Gross Torque - ISO 14396 450N·m
- Note (3) The labelled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC is 103 dB(A).
- Note (2) In certain applications, the loader's productive capabilities may exceed the tire's tonnes-km/h (ton-mph) capabilities.
- Note Net power advertised is the power available at the flywheel plus front drive implement pump when the engine is equipped with fan, air cleaner, muffler and alternator.
- Maximum Working Pressure - Implement Pump 23500kPa
- Note (3) Caterpillar recommends that you consult a tire supplier to evaluate all conditions before selecting a tire model.
- Other Choices Include 15.5-R25; 17.5-25 12PR; 17.5-25 12PR L2; 17.5-R25 XHA * L3; 17.5-R25 * L2/L3 PC RM; 17.5-25 16PR L3, 3PC Rim; 17.5-25 GY L2/L3; 17.5-25 12PR L2, SNOW; Flexport�
