US
METRIC
C280-6
KEY SPECS
- Minimum Rating 1760 ekW (2200 kVA)
- Maximum Rating 1820 ekW (2275 kVA)
- Frequency 50 Hz or 60 Hz
OVERVIEW
FEATURES AT A GLANCE
A3 ECU
CAN J1939 data link Waterproof connectors, Maintenance-free, Backup ECU for redundant governing
![]()
Load feedback, Programmable droop, Adjustable gain, Adjustable fuel/air ratio control, Histograms of engine operation, Cat Messenger display presents diagnostics and other engine parameters
![]()
Engine speed, Boost pressure, Throttle position, Fuel consumption rate, Inlet manifold temperature, Diagnostic codes and events, Configuration, Desired engine speed, Battery voltage, Engine load, Lifetime totals — engine hours, fuel burned, idle fuel, idle hours, Trip totals — average fuel rate, idle fuel, idle hours, engine hours, fuel burned, trip reset
![]()
Customer Interface Panel
Interfaces with standard Cat® Marine Monitoring System (PLC in Price List), Provides visual indication of ECU functionality, Accepts 4 — 20 mA or PWM remote throttle speed input, Marine alarm and protection
![]()
Electronic Unit Injectors
“Drop-in” installation, No threaded fuel connections, High pressure inside injector only, Does not require double wall fuel lines or leak collection device, Injector synchronization not required
![]()
SPECIFICATIONS
- Minimum Rating 1760 ekW (2200 kVA)
- Maximum Rating 1820 ekW (2275 kVA)
- Frequency 50 Hz or 60 Hz
- Speed 1000 rpm (50 hz) or 900 rpm (60 hz)
- Aspiration Turbocharged-Aftercooled
- Bore 280.0mm
- Stroke 300.0mm
- Displacement 111.0l
- Governor Type Electronic
- Fuel System EUI
- Compression Ratio 50 Hz 13.1
- Compression Ratio 60 Hz 13:1
- Engine Model In-line 6, 4-Stroke-Cycle Diesel
- Emissions/Fuel Strategy EPA Tier 2, IMO II
- Length 7120.0mm
- Width 1961.0mm
- Height 3934.0mm
- Weight - Estimated 8165.0kg
